Frame & Tongue
• 16,000 lb GVWR
• 8″ channel wrap tongue with toolbox
• 6×2 3/16″ tube frame
• 3″ channel crossmembers on 12″ centers
• Stake pockets, rubrails, and pipe spools
Coupler & Jack
• 2 5/16″ adjustable coupler
• 10K drop‑leg jack
Tilt Deck & Rear Section
• 6′ stationary deck with knife‑edge rear
• 2×8 treated wood floor
Axles & Suspension
• (2) 8K electric brake axles
• Torsion spring suspension, 22.5° up on both axles
Wheels & Tires
• (4) ST215/75R17.5 H‑rated tires
• (1) ST215/75R17.5 H‑rated spare tire
Fenders & Lighting<.span>
• Double broke diamond plate fenders
• Flushmount LED lights with standard sealed wiring harness
Finish
• MAXXD gray metallic paint over primer
Additional Features
• Two extra 5/8″ bull‑nose D‑rings welded to top of side channel
• Tool tray behind toolbox
